G9306 UHF RFID PET windshield sticker
Size:105*30mm
Material:PET
Product name: UHF RFID anti-tamper windshield tag
Product number: G9306
Product character:
1. General tag: global operation 860 to 960 MHz
2. Accord EPC Class1 Gen2 standard
3. The best solutions for Glass surface, windshield applications
4. Provide Logo printing according to customer's request, work distance above 10m
Product technique:
|
Performance Specifications |
|
|
Product model |
G9306 |
|
Frequency |
860～960MHz |
|
Standard |
ISO18000-6C(EPC-Gen2) |
|
Chip type |
Alien H9 |
|
Memory |
96~496bits EPC Number, 688bit user memory |
|
Working mode |
read or write |
|
Read distance |
read(1~10m) (Reader dependent) |
|
Write distance |
write(1~3m) (Reader dependent) |
|
Data retention |
10(yrs) |
|
Anti-collision |
yes |
|
Physical Characteristics |
|
|
Dimension |
105mm*35mm*0.3mm(customizes) |
|
Base material |
Transparent PVC |
|
Antenna material |
Aluminum |
|
Operating temperature |
-10℃~+70℃ |
|
Operating humidity |
≤80% |
|
Package |
200pcs/box |
|
Weight |
1±0.05kg/box |
Application:
1. Customize different size labels, like 4'' x 2'', 4''x 4'', 4''x6'' etc
2. Can be sticked on the windshield of car, and for parking management.
3. Also can stick on other glass surface product, with good reading range.
